Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine

Brand Name : Hwashi

Model Number : WL－SP－150K

Certification : CE

Place of Origin : China

MOQ : 1

Price : 20000

Payment Terms : L/C, T/T

Supply Ability : 5 pc/M

Delivery Time : 60 days

Packaging Details : film

Contact Now

Hwashi Multi-point Spot Welded Mesh Full Automatic Wire Mesh Welding Machine, wire shelves/rack making machine

Product Description
Our machines have been widely applied to various kinds of industries, such as kitchen utensils, automobile making, motorcycle manufacturing, glasses, hardware, household appliances, low-voltage apparatus, elevator, compressor, etc. Suitable for batch production of mesh, cages, fence, reinforced wire mesh. etc. Multi-point Spot Welding Full Automatic Wire Mesh Welding Machine
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
Multi-point Spot Welding Full Automatic Wire Mesh Welding Machine 1.This Gantry Row welding machine is specialized in fast production of wire mesh. It is suitable for the product with more y wire and less x wire. 2.The welding power source is three-phase. The welding manner is one-way double-layer automatic stepping feeding with 12 welding heads. (adjustable according to your product) 3.The effective welding width is 1200mm while the effective welding length is 3000mm. (adjustable according to your product)
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
1.Welding Power Source:Since the distance between wires is long, the welding head is suitable to conduct single-point welding. So the machine will choose the small power 150KW discharging transformer which is special used for resistance welding as the welding power source. To ensure the strength and stability of the welding, 2.Welding Control System: The secondary which is controlled by microcomputer will identify the output of current automatically in order to guarantee the constant current of each welding spot. In the meantime, the control system is equipped with the function of voltage compensation which is used for the automatic detection of the voltage change in order to ensure the constant strength of the welding spot. 3.Pressurized Mechanism: Multiple pressurized mechanisms are adopted to drive the row welding electrodes to conduct welding to each wire respectively.
Techincal parameters
No.
Model
WL-SQ-AC150K
WL-SQ-MF90K
1
Input Power
Two-phase
Three-phase
2
Rated Capacity
150KVAx2
90KVAx2
3
Rated Input Current
750A
270A
4
Rated Duty Cycle
25%
25%
5
Secondary Voltage Adjusting Grade
2
2
6
Max Secondary Floating Voltage
AC7.5V
DC9.8V
7
Secondary Max Short
Circuit Current
26KA
28KA
8
Continuous Working Current
20KA
22KA
9
Welding Transformer Insulation Grade
Grade F
10
Forcing Curve of Welding Machine
2 types
11
Storage Welding Model Number
30 types
12
Welding Electrode
6 sets
14
Effective Welding
Width
1200mm
15
Effective Welding
Width Length
1200mm
16
Automatic Mobile Speed
0.5m/sec
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
1.Adopt silicon controlled from SEMIKRON of West Germany or IXYS of United Stated with high precision and long service life. 2.Adopt integrated circuit from Motorola of U.S. and PLC from Japan SIEMENS with quick response and stable performance. 3.Adopt Japan Panasonic intelligent touch screen control system which is installed with automatic bug alarm system. 4.Adopt self-developed intelligent microcomputer welding control system to control the compensation for the fluctuation of circuit built-in voltage in order to ensure the fluctuation of voltage is within±15%. 5.Adopt South Korea SANWO pneumatic components with stable performance. 6.All the electronic components are from Japan Mitsubishi and Omron with ideal service life and performance. 7.The transformer adopts Japan high purity silicon steel sheet with good magnetic and electricity conductivity.
Mechanical Manufacturing Process
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
Cooperrated Customers
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
Company introduction
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
FAQ
Hwashi Multi Point Spot Welding Machine Wire Mesh / Shelves / Rack Making Machine
